Operator Information Process
MTS MultiPurpose TestWare® Other Process Descriptions 417
General tab
How to Define an Operator Information Process without Variables
1. Drag the icon from the Process Palette to your group or procedure
table.
2. Click the process icon in your group or procedure table, or in the navigation
pane.
3. Click the Parameters tab, and then click to create an item.
4. In the Label box, type the text you want to appear when the runtime
window is displayed.
5. In the Type list, click the item type, and then click the Attribute.
6. In the Dimension list, click the dimension (real types only).
7. In the Selections panel, add, arrange, and label custom list items (list types
only).
8. In the Default Value box, type a default value.
9. Enter Minimum and Maximum values (real and integer types only).
General Tab
I TEM D ESCRIPTION
Name Specifies the process name displayed on the Procedure or Group process
window.
Process Enabled Enables the process. (Clear this box to disable the process.)
Execute Process Specifies the number of times the process will be run.
Counter Type Enables a process counter.
Options are None, Transient, or Fixed. Transient counters are displayed only
when the process is active. Fixed counters are displayed throughout the test.
Counter Label Names the counter.
When you run the test, this name appears under Sequence Counters on the
MPT control panel.
Note If this box is blank, the process name is used as the counter label.
