MTS MultiPurpose TestWare®
The MultiPurpose TestWare Interface
About MultiPurpose TestWare 22
MPT control panel The MPT control panel appears in the application area of Station Manager, as
shown.
MPT application button
When you launch MPT this
button appears in the
applications control panel.
You can quickly select
among launched
applications with the buttons
in this panel.
Channel Counters
Channel Counters display
the cumulative count of
segments applied to
specific channels.
MPT toolbar
Sequence Counters
Sequence counters display
current and target counts for
processes. Individual process
counters are arranged
according to the process icons
on the Procedure Editor. Group
process counters are indented
to show nesting.
MPT Procedure Editor button
Displays the Procedure Editor and
Process Palette, as shown on the
next page. Station Controls
You run MPT procedures with
the run, stop, and hold
controls.
