Chapter 2
66
External Device Setup Manual
2.2.7 MELSEC-FX Series (connects to FX2NC-232ADP/FX3U-232ADP)
MICRO/I
RS232C
Connection Dia-
gram 8
FX1NC FX2NC-232ADP
FX2NC
RS232C MICRO/I
Connection Diagram
8
FX1N + FX1N-CNV-BD
FX2NC-232ADP
FX2N + FX2N-CNV-BD
MICRO/I
RS232C
Connection Dia-
gram 8
FX3UC
FX3U
FX3G
FX3UC-232ADP
