Chapter 2
440
External Device Setup Manual
18.2.3 MICREX-F Series (Interface Card)
• F55
• F70
• F80H/F120H/F120S/F140S/F150S
MICREX-F F55 NV1L-RS2 MICRO/I
RS232C
Connection Diagram 5
NC1L-RS2 MICRO/I
RS232C
Connection Diagram 5
MICREX-F F70
NC1L-RS4 MICRO/I
RS485 4-wire
Connection Diagram 6
MICREX-F FFU-120B MICRO/I
RS232C
Connection Diagram 5
MICREX-F FFU-120B MICRO/I
RS485 4-wire
Connection Diagram 6
