22 Emerson
2
Con
nection
to a PLC
External Device Setup Manual
22.2 System Configuration
This is the system configuration for the connection of Emerson PLCs to the MICRO/I.
22.2.1
FloBoss
RS485
Connection Diagram 1
MICRO/I
COM1
COM2
RS232C
Connection Diagram 2
