External device setup manual – IDEC High Performance Series User Manual
Page 177

159
3 Omron
2
2
2
2
2
2
2
2
2
2
2
2
2
2
2
Con
nection
to a PLC
External Device Setup Manual
3.5.3
SYSMAC-CS1/CJ1 Ethernet (When the PLC type setting is SYSMAC-CS1/CJ1 Ethernet)
Bit Device
Device Name
Device Symbol
Address Range
Read
/Write
Address
Gradual
MICRO/I
PLC
Core I/O
CIO
CIO
0 - 614315
R/W
Work Area
WR
WR
0 - 51115
R/W
Holding Bit
HR
HR
0 - 51115
R/W
Auxiliary Bit
AR
AR
0 - 95915
R
Timer (Contact)
TIMC
TIMC
0 - 4095
R
Counter (Contact)
CNTC
CNTC
0 - 4095
R
Task Area
TK
TK
0 - 31
R
