515

21 VIGOR

2

2

2

2

2

2

2

2

2

2

2

2

2

2

2

Con

nection

to a PLC

External Device Setup Manual

21.2 System Configuration

This is the system configuration for the connection of VIGOR PLCs to the MICRO/I.

21.2.1

VB0, VB1, VB2, VH (Programming Tool Communication Port)

21.2.2

VB0, VB1, VB2, VH (VB-485A)

21.2.3

VB0, VB1, VB2, VH (VB-CADP)

VB0, VB1, VB2, VH

MICRO/I

RS232C

Connection Diagram 1

VB0, VB1, VB2, VH

VB-485A

MICRO/I

RS485

Connection Diagram 2

VB0, VB1, VB2, VH

VB-CADP

MICRO/I

RS232C

Connection Diagram 3

VB-CADP

MICRO/I

RS485 2-wire

Connection Diagram 4
