Page 142

Chapter 2
124
External Device Setup Manual
3.2.2
SYSMAC-C Series (using the Link I/F on the CPU Unit)
You can use the same cable for Connection Diagram 6 as for Connection Diagram 5.
MICRO/I
RS232C
Connection Diagram 4
C20H, C28H, C40H and C60H
MICRO/I
RS232C
Connection Diagram 5
C200HS-CPU21/23/31/33
CQM1H
- In case of HG2F/3F/4F a connection cable is available for Connection Diagram 5 (part number: HG9Z-3C155).
- In case of HG1F a connection cable is available for Connection Diagram 5 (part number: HG9Z-XC213).
C200H
MICRO/I
RS232C
Connection Diagram 6
C200HE-CPU42
C200HG-CPU43/63
C200HX-CPU44/64
