External device setup manual – IDEC High Performance Series User Manual
Page 185

167
4 Allen-Bradley
2
2
2
2
2
2
2
2
2
2
2
2
2
2
2
Con
nection
to a PLC
External Device Setup Manual
4.2.5
MicroLogix 1500 (D-sub 9 Pin connector on CPU Unit)
4.2.6
Ethernet/IP (MicroLogix, PLC-5, SLC 500, ControlLogix, CompactLogix)
MICRO/I
RS232C
Connection Diagram 6
MicroLogix1500
MICRO/I
ControlLogix + 1756-
ENBT
PLC-5E
SLC5/03 + 1761-NET-
ENI
MicroLogix + 1761-NET-ENI
CompactLogix 1769
PLC-5 + 1785-ENET
SLC5/04 + 1761-NET-
ENI
MicroLogix 1100
SLC5/05 + 1761-NET-
ENI
Built-in Ethernet port
SLC5/05
Connect to maximum of 16 different PLCs
- Use a crossover cable to connect the MICRO/I and PLC directly.
- When using a hub (Ethernet switch), use a cable that can be used with the hub.
