Chapter 2
286
External Device Setup Manual
Word Device
WindO/I-NV2 Device
Name
R/W
WindO/I-NV2 address
PLC Device Name
PLC address
Timer (Current Value)
R
TC0 - TC777
Timer
(Current Value)
0000 - 0777
Ext.Counter(Current Value)
R
ETC1000 - ETC1777
1000 - 1777
Counter (Current Value)
R
CC0 - CC777
Counter
(Current Value)
0000 - 0777
Ext.Counter (Current Value)
R
ECC1000 - ECC1777
1000 - 1777
Register (A)
R/W
RA0 - RA1576
Register
a0000 - a1576
Ext.Register (A)
R/W
ERA2000 - ERA7576
a2000 - a7576
Register (B)
R/W
RB0 - RB1776
b0000 - b1776
Ext.Register (B)
R/W
ERB2000 - ERB3776
b2000 - b3776
Register (09)
R/W
R09_ 0 - R09_ 776
09000 - 09776
Register (19)
R/W
R19_ 0 - R19_ 776
19000 - 19776
Register (29)
R/W
R29_ 0 - R29_ 776
29000 - 29776
Register (39)
R/W
R39_ 0 - R39_ 776
39000 - 39776
Register (49)
R/W
R49_ 0 - R49_ 776
49000 - 49776
Register (59)
R/W
R59_ 0 - R59_ 776
59000 - 59776
Register (69)
R/W
R69_ 0 - R69_ 776
69000 - 69776
Register (79)
R/W
R79_ 0 - R79_ 776
79000 - 79776
Register (89)
R/W
R89_ 0 - R89_ 776
89000 - 89776
Register (99)
R/W
R99_ 0 - R99_ 776
99000 - 99776
Register (E)
R/W
RE0 - RE1776
E0000 - E1776
Ext.Register (E)
R/W
ERE2000 - ERE7776
E2000 - E7776
System Memory
R
S0 - S2176
System Memory
#0000 - #2176
File Register (1)
R/W
F1_ 0 - F1_ 37776
File Register1
000000 - 037776
File Register (2)
R/W
F2_ 0 - F2_ 177776
File Register2
000000 - 177776
File Register (3)
R/W
F3_ 0 - F3_ 177776
File Register3
000000 - 177776
- Set all devices using octal.
- Confirm the PLC manuals as device or device address may not use according to PLC.
- R/W specifies Read and Write device. R specify Read only device.
- Word device address below “Register (A)” increase +2. (The other device increase +1.)
- Device address of WindO/I NV2 does not display as the number of figure used PLC.
Example: if you set to “Register 19005” using WindO/I NV2, it set to not “R19_ 005” but “R19_5”.
