Page 46

Chapter 2
28
External Device Setup Manual
MICROSmart
Pentra
FC5A-D12K1E
FC5A-D12S1E
Not required
(connects to CPU unit)
Ethernet
-
Web Server Unit
(FC3A/FC4A/FC5A)
FC4A-HPC1
RS232C
Connection Diagram 1
(refer to P37)
Hardware
OpenNet(FC3A),
MicroSmart
(FC4A/FC5A)
FC4A-HPC3
RS422/485 2-wire
Connection Diagram 2
(refer to P40)
FC4A-HPH1
+FC4A-PC1
RS232C
Connection Diagram 1
(refer to P37)
FC4A-HPH1
+FC4A-PC3
RS422/485 2-wire
Connection Diagram 2
(refer to P40)
FC5A-SIF2
RS232C
Connection Diagram 4
(refer to P46)
None
FC5A-SIF4
RS422/485 2-wire
Connection Diagram 2
(refer to P40)
*1. We tested with the PLC of these parts.
Series Name
System
(CPU unit)
Link unit
WindO/I-NV2 Settings
Interface
Flow
Control
Host I/F Driver
