Chapter 2
188
External Device Setup Manual
4.4.2
SLC 500 (Half Duplex)
Item
Setting
Interface
RS232C
Baud Rate (bps)
*1*2
*1. Set using RSLogix500 (set Chan0 to System of Controller-Channel Configuration).
*2. The setting for this item must match the setting on the MICRO/I Series unit.
1200, 2400, 4800, 9600 or 19200
Data Bits
8 (fixed)
Parity
None or Even
1
DF1
Half-Duplex
Slave
*3
*3. Be certain to set as indicated.
Error Detect
Control Line
handshaking
Node Address
*4.Set the MICRO/I Node Address using the Node Address (MICRO/I) setting in Configuration-System Setup-Project-Host
I/F Driver of WindO/I-NV2.
0 to 254 (decimal)
