3 Omron
2
2
2
2
2
2
2
2
2
2
2
2
2
2
2
Con
nection
to a PLC
External Device Setup Manual
You can use the same cable for Connection Diagram 6 as for Connection Diagram 5.
SYSMAC-CS1
Communication Board
MICRO/I
RS232C
Connection Diagram 6
CS1W-SCB41(port1)
MICRO/I
RS422
Connection Diagram 7
CS1W-SCB41(port2)
MICRO/I
RS232C
Connection Diagram 5
CPM1,
CPM1A,
CPM2A
Omron RS232C Adapter
CPM1-CIF01
MICRO/I
RS422
Connection Diagram 8
CPM1,
CPM1A,
Omron RS422 Adapter
CPM1-CIF11
CPM2A
- In case of HG2F/3F/4F a connection cable is available for Connection Diagram 5 (part number: HG9Z-3C155).
- In case of HG1F a connection cable is available for Connection Diagram 5 (part number: HG9Z-XC213).
