21.5 Usable Devices
Device Address 992 in Step Relay (Word) only contains 8bits because the maximum device address of Step Relay (Bit) is
999.
Bit Device
Device Name
Device Symbol
Address Range
Read
/Write
Address
Gradual
MICRO/I
PLC
Input Relay(Bit)
X
X
0 - 777
R
OCT
Output Relay(Bit)
Y
Y
0 - 777
R/W
OCT
Auxiliary Relay(Bit)
M
M
0 - 5119
R/W
DEX
Step Relay
S
S
0 - 999
R/W
DEX
Special Relay
SM
M
9000 - 9255
R/W
DEX
Timer Contact
T
T
0 - 255
R
DEX
Timer Coil
TC
T
0 - 255
R
DEX
Counter Contact
C
C
0 - 255
R
DEX
Counter Coil
CC
C
0 - 255
R
DEX
Word Device
Device Name
Device Symbol
Address Range
Read
/Write
Address
Gradual
MICRO/I
PLC
Input Relay(Word)
WX
X
0 - 769
R
OCT
Output Relay(Word)
WY
Y
0 - 760
R/W
OCT
Auxiliary Relay(Word)
WM
M
0 - 5104
R/W
DEX
Step Relay(Word)
WS
S
0 - 992
R/W
DEX
Special Relay(Word)
WSM
M
9000 - 9240
R/W
DEX
Data Registor
T
D
0 - 8191
R/W
DEX
Special Registor
SD
D
9000 - 9255
R/W
DEX
Timer Current Value
TCV
T
0 - 255
R/W
DEX
16 Bit Counter
Current Value
CCV
C
0 - 199
R/W
DEX
32 Bit Counter
Current Value
DCCV
C
2000 - 2551
R/W
DEX
