Word Device
Device Name
Device Symbol
Address Range
Read
/Write
Addres
s
Gradual
MICRO/I
PLC
Input
WI
I
0 - 301
R
10
*1
*1. Address selection rule is as follows.
Output
WO
O
0 - 301
R
10
Bit
WB
B
3000 - 3255,
10000 - 255255
R/W
10
*2
Timer
(accumulated value)
TA
T
4000 - 4255,
10000 - 255255
R
10
Counter
(accumulated value)
CA
C
5000 - 5255,
10000 - 255255
R
10
Timer (preset value)
TP
T
4000 - 4255,
10000 - 255255
R/W
10
Counter
(preset value)
CP
C
5000 - 5255,
10000 - 255255
R/W
Integer
*3
N
N
7000 - 7255,
10000 - 255255
R/W
10
ASCII
A
A
10000 - 255255
R/W
10
