Con
nection
to a PLC
External Device Setup Manual
Word Device
Device Name
Device
Symbol
MicroLogix/SLC500
PLC-5
ControlLogix
CompactLog
ix
SLC/MicroLogix Input (Word)
SWI
Input (Word)
-
-
SLC/MicroLogix Output
(Word)
SWO
Output (Word)
-
-
PLC-5 Input (Word)
PWI
-
Input (Word)
-
PLC-5 Output (Word)
PWO
-
Output (Word)
-
Status
S
Status
Status
-
Timer (Preset Value)
TP
Timer (Preset Value)
Timer (Preset Value)
-
Timer (Accumulated Value)
TA
Timer (Accumulated Value)
Timer (Accumulated Value)
-
Counter (Preset Value)
CP
Counter (Preset Value)
Counter (Preset Value)
-
Counter (Accumulated Value)
CA
Counter (Accumulated
Value)
Counter (Accumulated
Value)
-
Control LEN
RLEN
Control LEN
-
-
Control POS
RPOS
Control POS
-
-
Bit (Word)
WB
Bit (Word)
Bit (Word)
-
Integer
N
Integer
Integer
INT
Float/REAL
F
Float
-
REAL
Long/DINT
L
Long
-
DINT
Ascii
A
Ascii
Ascii
-
BCD
BCD
-
BCD
-
SINT
SINT
-
-
SINT
