External Device Setup Manual
1.2
System Configuration
This is the system configuration for the connection of IDEC PLCs to the MICRO/I.
1.2.1
OpenNet Controller (connects to RS232C port of the CPU unit)
1.2.2
OpenNet Controller (connects to RS485 port of the CPU unit)
FC3A-CP2
MICRO/I
OpenNet Controller Interface
Connection Diagram 1
- In case of HG2G-5F, HG3G/4G a connection cable is available. (part number: HG9Z-XC295).
- In case of HG2G-S/-5S/-5F, HG3G/4G a connection cable is available. (part number: HG9Z-XC275).
- In case of HG2F/3F/4F a connection cable is available. (part number: HG9Z-3C125).
- In case of HG1F a connection cable is available. (part number: HG9Z-XC183).
FC3A-CP2
MICRO/I
OpenNet Controller Interface
Connection Diagram 2
