Chapter 2
512
External Device Setup Manual
20.4 Environment Settings
Refer to the followings to configure the communication port between PLC (PROSEC T Series or V Series) and MICRO/I.
Attend to the limitation of the configuration. It depends on the CPU unit and Link unit.
20.4.1
LG Industrial Systems MASTER-K K10S1, K80S, K120S, K200S (Loader Port)
20.4.2
LG Industrial Systems MASTER-K K80S, K200S, K300S (Interface Module)
Refer to the MASTER-K Series user’s manual for details of communication settings.
Items
Details
Interface
RS232C
Baud Rate [bps]
38400
Data Bits
8
Parity
None
Stop Bits
1
Flow Control
None
Items
Details
Interface
RS232C, RS485 4-wire
Baud Rate [bps]
1200, 2400, 4800, 9600, 19200 or 38400
Data Bits
7 or 8
Parity
None, Odd or Even
Stop Bits
1 or 2
Flow Control
None or Hardware
Station No.
00 - 1F(HEX)
