Chapter 2
340
External Device Setup Manual
12 Panasonic Electric Works
12.1 Connection Table
12.1.1
Compatible Protocols
Series Name
System
(CPU unit)
Link Unit
WindO/I-NV2 Settings
Interface
Flow Control
Host I/F Driver
FP Series
FP0
(Connects to CPU unit directly)
RS232C
Connection Diagram 1
(refer to P344)
Hardware
MEWNET
FP1
*1
*1. We tested with the PLC of these parts.
Not required
(Connects to RS232C Port)
RS232C
Connection Diagram 2
(refer to P346)
Not required
(Connects to CPU unit directly)
RS232C (AFP8550)
Connection Diagram 3
(refer to P348)
(Connects to CPU unit directly)
RS422/485 4-wire
Connection Diagram 4
(refer to P351)
FP
(Connects to CPU unit directly)
RS232C
Connection Diagram 1
(refer to P344)
Used Communication cassette
AFPG801
RS232C
Connection Diagram 5
(refer to P354)
Used Communication cassette
AFPG802
RS232C
Connection Diagram 6
(refer to P356)
Used Communication cassette
AFPG803
RS422/485 2-wire
Connection Diagram 7
(refer to P358)
FP10,
FP10SH
(Connects to Tool Pot or Com
Port)
RS232C
Connection Diagram 8
(refer to P361)
AFP3462
FP2,
FP2SH
Not required
(Connects to Com Port)
AFP2462
