Chapter 2
364
External Device Setup Manual
12.4.4
FP10 and FP10SH (tool port on CPU unit).
12.4.5
FP2, FP2SH, FP10 and FP10SH (Communication port on CPU unit)
12.4.6
FP10 and FP10SH (Computer Communication Unit)
12.4.7
PLC FP2 and FP2SH (Computer Communication Unit)
Items
Details
Interface
Use the same
settings as for the MICRO/I.
RS232C
Slave Address
1 - 32(DEC)
Baud Rate (bps)
9600 or 19200
Data Bits
7 or 8
Parity
Odd
Stop Bits
1
Flow Control
Hardware or None
Items
Details
Interface
Use the same
settings as for the MICRO/I.
RS232C
Slave Address
1 - 32(DEC)
Baud Rate (bps)
2400, 4800, 9600, 19200, 38400, 57600 or 115200
Data Bits
7 or 8
Parity
None, Even or Odd
Stop Bits
1 or 2
Flow Control
Hardware or None
Items
Details
Interface
Use the same
settings as for the MICRO/I.
RS232C
Slave Address
1 - 32(DEC)
Baud Rate (bps)
2400, 4800, 9600, 19200, 38400, 57600 or 115200
Data Bits
7 or 8
Parity
None, Even or Odd
Stop Bits
1 or 2
Flow Control
Hardware or None
Items
Details
Interface
Use the same
settings as for the MICRO/I.
RS232C
Slave Address
1 - 32(DEC)
Baud Rate (bps)
4800, 9600, 19200, 38400, 57600 or 115200
Data Bits
7 or 8
Parity
Odd
Stop Bits
1
Flow Control
Hardware or None
