Chapter 2
536
External Device Setup Manual
22.3 Connection Diagram
The connector types given in the Connection Diagrams are for the unit and not the cable. For details regarding wiring, refer
to Chapter 1 "3 Important Points Regarding Wiring" on page 19.
22.3.1
Connection Diagram 1: FloBoss (COM1, RS485)
Terminal
D-sub, 9P connector plug type
Terminal
Terminal
