Chapter 2
532
External Device Setup Manual
21.4 Environment Settings
The communication port settings for VB/VH series and MICRO/I host port are as follows.
21.4.1
VB/VH Series (Communication Port for Programming Tool)
21.4.2
VB/VH Series (VB-485A, VB-232 or VB-485)
21.4.3
VB/VH Series (VB-CADP)
Refer to the VB/VH Series user’s manual for details of communication settings.
Items
Details
Interface
RS232C
Baud Rate [bps]
Use the same settings as
for the MICRO/I.
19200 (fixed)
Data Bits
7 (fixed)
Parity
Even
Stop Bits
1 (fixed)
Flow Control
None
Station Number
0 (fixed)
Items
Details
Interface
RS232C, RS485 4-wire
Baud Rate [bps]
Use the same settings as
for the MICRO/I.
1200, 2400, 4800, 9600, 19200 or 38400
Data Bits
7
Parity
Even
Stop Bits
1
Flow Control
None
Station Number
0 - 255(DEC)
Items
Details
Port
CP2
CP3
Interface
RS232C, RS485
RS485
Baud Rate [bps]
Use the same settings as
for the MICRO/I.
1200, 2400, 4800, 9600, 19200 or 38400
19200
Data Bits
7
7
Parity
Even
Even
Stop Bits
1
1
Flow Control
None
None
Station Number
0 - 255(DEC)
0 - 99(DEC)
