Chapter 5
602
External Device Setup Manual
•
Compact Controller + Communication Adapter
MICRO/I
Touch
RS232C
Connection Diagram 1
TWD LC*A 16DRF
TWDNAC232D
TWD LC*A 24DRF
(Communication Adapter)
TWD LCA* 40DRF
MICRO/I
Touch
RS485
Connection Diagram 2
TWD LC*A 16DRF
TWDNAC485D
TWD LC*A 24DRF
(Communication Adapter)
TWD LCA* 40DRF
MICRO/I
Touch
RS485
Connection Diagram 3
TWD LC*A 16DRF
TWDNAC485T
TWD LC*A 24DRF
(Communication Adapter)
TWD LCA* 40DRF
