Chapter 2
98
External Device Setup Manual
2. PLC Settings
Refer to the Q Corresponding Ethernet Interface Module User’s Manual or Q Corresponding Ethernet Interface Module
User’s Manual for detail.
Item
setting
notes
Network parameter
Network type
Ethernet
*1
*1. The setting of the above-mentioned is recommended.
Starting I/O No.
0020
*2
*2. Set it according to the environment.
Network No.
1
Total stations
-
-
Group No.
0
Station No.
1
Mode
On line
Operation Setting
Communication data code
Binary code
Initial Timing
Always wait for OPEN
IP Address
Input format
Decimal
IP address
Set IP address of PLC
Send frame setting
Ethernet
Enable Write at RUN time
Check mark (enable)
TCP Existence confirmation setting
Use the Keep Alive
Open Setting
Protocol
TCP/IP
Open system
Impassive open
Fixed buffer
Send
Fixed buffer communication
Procedure exist
Pairing open
No pairs
Existence confirmation
No confirm
Local station Port No.
Set an arbitrary port number
*3
*3. MICRO/I is set by the decimal number though PLC is set by the hexadecimal number.
Destination IP address
-
-
Dest. Port No.
-
-
