External Device Setup Manual
9.4
Environment Settings
9.4.1
TOYOPUC-PC3J Series
Item
Setting
Interface
RS422/485 2-wire
Station No.
0-37 (set with octal number)
*1
*1. Although a Station No. is the number of octal in PC3J, please set it up with the number of Hexadecimal by WindO/I-NV2.
For example, when set up with “37” in PC3J, please set up with “1F” in WindO/I-NV2.
Data Bits
7 or 8
Communication Speed (bps)
1200, 2400, 4800, 9600, 19200, 38400 or 57600
Parity
Even (fix)
Stop Bits
1 or 2
- Please set the communication conditions of PC3J in the built-in standard link parameters.
- When the built-in standard link parameters are not set, the link acts as the computer link for below settings.
Communication Speed: 19200bps
Data length: 8bit
Stop bit: 1bit
Parity: Even
Station No.: 0
- Please refer to “JTEKT TOYOPUC PC3J CPU MODULE OPERATION MANUAL” for details.
