External device setup manual – IDEC High Performance Series User Manual
Page 143

125
3 Omron
2
2
2
2
2
2
2
2
2
2
2
2
2
2
2
Con
nection
to a PLC
External Device Setup Manual
You can use the same cable for Connection Diagram 6 as for Connection Diagram 5.
SYSMAC-CS1
MICRO/I
RS232C
Connection Diagram 6
- In case of HG2F/3F/4F a connection cable is available for Connection Diagram 5 (part number: HG9Z-3C155).
- In case of HG1F a connection cable is available for Connection Diagram 5 (part number: HG9Z-XC213).
MICRO/I
RS232C
Connection Diagram 6
Omron RS232C Adapter
CP1W-CIF01
CP1H
MICRO/I
RS422
Connection Diagram 7
CP1H
Omron RS422 Adapter
CP1W-CIF11
