Chapter 5
616
External Device Setup Manual
1.4
Environment Settings
1.4.1
Twido
1.4.2
Momentum (Modbus TCP Client)
Items
Details
Interface
The same setting as MICRO/I
or Touch
RS232C, RS485 2-wire
Slave Address
*1
*1. Set a decimal number for the Slave Address.
1 - 247(DEC)
Baud Rate (bps)
1200, 2400, 4800, 9600, 19200 or 38400
Data Bits
7 or 8
Parity
None, Even or Odd
Stop Bits
1 or 2
Flow Control
Hardware
Use No.0 as Broadcast
0: Disable, 1: Enable
Use function6 instead of function16
Use function6 for writing to HR
Items
Items
Details
Interface
--
*1
*1. These settings will be ignored since it is using the Ethernet port.
Slave Address
Baud Rate (bps)
Data Bits
Parity
Stop Bits
Unit ID
*2
*2. Set a decimal number for the unit ID.
The same setting as MICRO/I
or Touch
1 - 247(DEC)
Destination Address
*3
*3. Destination Address and Port Number cannot be changed from the system menu of MICRO/I or Touch . Please change it using WindO/I-NV2,
WindO/I-NV3 software.
IPv4 Typed IP address
Port Number
0 to 32767
*4
*4. If “0” is set, this driver will set “502” (the number of Modbus TCP default port) automatically.
