External Device Setup Manual
1.4
Environment Settings
1.4.1
OpenNet Controller and MICROSmart
When connecting an OpenNet Controller to the MICRO/I, you must set the OpenNet Controller special Internal Relay
M8014 to on.
1.4.2
OpenNet Controller, MICROSmart/MICROSmart Pentra (uses Web Server Unit)
Set the following items on Project Settings dialog box.
Item
Setting
Baud Rate (bps)
9600
Data Bits (bits)
7
Parity
Even
Stop Bits
1
Network Number
*1
*1. Set a decimal number for the Network Number.
0(DEC)
Item
Setting
IP Address (MICRO/I)
Set the IP address for MICRO/I.
(Set this item in Communication Interface tab.)
Subnet Mask
Set the subnet mask for MICRO/I.
(Set this item in Communication Interface tab.)
Default Gateway
Set the default gateway for MICRO/I.
(Set this item in Communication Interface tab.)
IP Address (Web Server Unit)
Set the IP address for Web Server Unit.
(Set this item in Host I/F Network tab.)
Port Number (Web Server Unit)
Set the port number for Web Server Unit.
(Set this item in Host I/F Network tab.)
- When connecting an OpenNet Controller to the MICRO/I, you must set the OpenNet Controller special Internal Relay
M8014 to on.
- If the HG3F/4F is connected to the IDEC Web Sever Unit, the communication speed of the Web Sever Unit (Ethernet)
must be set to “10 Base” or “Auto”.
