13 YASKAWA ELECTRIC CORPORATION
2
2
2
2
2
2
2
2
2
2
2
2
2
2
2
Con
nection
to a PLC
External Device Setup Manual
13.5 Usable Devices
Bit Device
Device Name
Device Symbol
Address Range
Read
/Write
Address
Gradual
MICRO/I
PLC
Coil
MB
MW
0 - 4095F
R/W
*1
*1. Upper four digits: Register Number (decimal)
The lowest digit: Bit Number (hexadecimal)
Example: 4095F 4095: Register Number, F: Bit Number
Inputs Status
IB
IW
0 - FFFFF
R
Hexadeci-
mal
Word Device
Device Name
Device Symbol
Address Range
Read
/Write
Address
Gradual
MICRO/I
PLC
Holding Registers
MW
MW
0 - 65535
R/W
Decimal
Inputs Registers
IW
IW
0 - FFFF
R
Hexadeci-
mal
