External device setup manual – IDEC High Performance Series User Manual
Page 415

397
14 Koyo
2
2
2
2
2
2
2
2
2
2
2
2
2
2
2
Con
nection
to a PLC
External Device Setup Manual
14.4.4
Ethernet Unit on DirectLogic
Set the following items on Configuration-System Setup-Project dialog box.
Item
Setting
IP Address (MICRO/I)
Set the IP adress of MICRO/I in Communication Interface tab.
Subnet Mask
Set the subnet mask of MICRO/I in Communication Interface tab.
Default Gateway
Set the default gateway of MICRO/I in Communication Interface tab.
IP Address (Ethernet Unit)
Set the IP adress of Ethernet unit in Host I/F Network tab.
Port Number (Ethernet Unit)
Set the port number of Ethernet unit in Host I/F Network tab.
