Page 494

Chapter 2
476
External Device Setup Manual
19.2 System Configuration
This is the system configuration for the connection of Toshiba PLCs to the MICRO/I.
19.2.1
PROSEC T Series T1
19.2.2
PROSEC T Series T1S
T1
MICRO/I
RS232C
Connection Diagram 4
CU111
MICRO/I
RS485
Connection Diagram 5
T1S
MICRO/I
RS232C
Connection Diagram 4
MICRO/I
RS485
Connection Diagram 3
CU111
MICRO/I
RS485
Connection Diagram 5
