11.4 Environment Settings
The communication port settings for GE Fanuc PLCs and MICRO/I host port are as follows
11.4.1
Series 90-30 Communication Coprocessor Module (CMM)
Do not set SNP ID for the PLC. If you set it, MICRO/I will not communicate with PLC.
11.4.2
Series 90-30 CPU Module
Do not set SNP ID for the PLC. If you set it, MICRO/I will not communicate with PLC.
Item
Setting
Interface
Set to the same setting
as the MICRO/I
RS232C
RS485 4-wire
Baud Rate [bps]
1200, 2400, 4800, 9600 or 19200
Data Bits
8 (fixed)
Parity
Odd , Even or None
Stop Bits
1 or 2
Flow Control
None
Hardware or None
Configuration Mode
SNP Only
SNP Enable
Yes
SNP Mode
Slave
Item
Setting
Interface
Set to the same setting
as the MICRO/I
RS485 4-wire
Baud Rate [bps]
1200, 2400, 4800, 9600 or 19200
Data Bits
8 (fixed)
Parity
Odd , Even or None
Stop Bits
1 or 2
