IDEC High Performance Series - Manual (Page 360)

Chapter 2
342
External Device Setup Manual
FP AFPG801 MICRO/I
RS232C
Connection Diagram 5
C32T, C24R2, C32T2
FP AFPG802 MICRO/I
RS232C
Connection Diagram 6
C32T, C24R2, C32T2
FP AFPG803 MICRO/I
RS485
Connection Diagram 7
C32T, C24R2, C32T2
MICRO/I
RS232C
Connection Diagram 8
FP2, FP2SH
FP10, FP10SH
