4.6.4

Setting Example for WindO/I-NV2

Refer to the following about setting an example for WindO/I-NV2 software.

(PLC station number is 0 in the example.)

*The setting example uses Allen-Bradley device address format.

Example1: Set an array number 0 in Tag_A.
0: INT 1:0

Example2: Set an array number 5 in Tag_B.
0: SINT 2:5

Example3: Set a lower word on array number 3 in Tag_C.
0: DINT 3:3_0

Example4: Set an upper word on array number 9 in Tag_D.
0: REAL 4:10_1

Note:
Need to set upper word or lower word in WindO/I-NV2 software when use 32 bit device.
Add “_0” after array number when use lower word.
Add “_1” after array number when use upper word.

Tag name

Data Tyde

Array

File Number

Tag_A

INT

-

1

Tag_B

SINT

[10]

-

2

Tag_C

DINT

[10]

-

3

Tag_D

REAL

[10]

-

4
