2
2
2
2
Con
nection
to a PLC
External Device Setup Manual
Word Device
Device Name
Device Symbol
Address Range
Read
/Write
Address
Gradual
MICRO/I
PLC
Input Relay
XW
X
201 - 71649
R
*1
*1. Please specify in the following ranges.
Output Relay
YW
Y
201 - 71649
R/W
Int. Relay
IW
I
1 - 65521
R/W
Dec
Comm. Relay
EW
E
1 - 4081
R/W
Dec
Link Relay
LW
L
1 - 78177
R/W
*2
*2. Please specify in the following ranges.
Spec. Relay
MW
M
1 - 9969
R/W
Dec
Timer (Current Value)
TP
T
1 - 3072
R/W
Dec
Timer (Preset Value)
TS
T
1 - 3072
R
Dec
Counter (Current Value)
CP
C
1 - 3072
R/W
Dec
Counter (Preset Value)
CS
C
1 - 3072
R
Dec
Data Register
D
D
1 - 65536
R/W
Dec
Comm. Register
R
R
1 - 4096
R/W
Dec
File Register
B
B
1 - 99999
R/W
Dec
Link Register
W
W
1 - 74096
R/W
*3
*3. Please specify in the following ranges.
Spec. Register
Z
Z
1 - 1024
R/W
Dec
