Chapter 2
262
External Device Setup Manual
7
SHARP
7.1
Connection Table
7.1.1
Compatible PLCs
Series Name
System
(CPU unit)
Link unit
WindO/I-NV2 Settings
Interface
Flow Control
Host I/F Driver
New Satellite JW
JW-10
Not required
(connects to CPU unit)
RS422-MMI Port
Connection Diagram 6
(refer to P278)
Hardware
JW
RS422/485 2-wire
Connection Diagram 7
(refer to P281)
JW-21CU,
JW-22CU,
JW-31CUH/H1,
JW-32CUH/H1,
JW-33CUH/H1
*1
/
H2/H3
*1. We tested with the PLC of these parts.
JW-21CM
RS422/485 2-wire
Connection Diagram 1
(refer to P265)
RS422/485 4-wire
Connection Diagram 2
(refer to P268)
JW-50CU/CUH,
JW-70CU/CUH,
JW-100CU/CUH
JW-10CM
RS422/485 4-wire
Connection Diagram 2
(refer to P268)
JW-22CU,
JW-70CU/CUH,
JW-100CU/CUH
Not required
(connects to CPU unit)
RS232C
Connection Diagram 3
(refer to P271)
JW-32CUH/H1,
/
H2/H3
RS232C
Connection Diagram 4
(refer to P273)
RS422/485 4-wire
Connection Diagram 5
(refer to P275)
