Chapter 2
156
External Device Setup Manual
3.5
Usable Devices
3.5.1
SYSMAC-C (when the PLC type setting is SYSMAC-C Series)
Bit Device
Device Name
Device Symbol
Address Range
Read
/Write
Address
Gradual
MICRO/I
PLC
Input/Output Internal Relay
R
CIO
0 - 99915,
120000 - 614315
R/W
Link Relay
LR
LR
0 - 19915
R/W
Holding Relay
HR
HR
0 - 51115
R/W
Auxiliary Memory
Relay
AR
AR
0 - 95915
R
Timer (contact)
TIMC
TC
0 - 2047
R
Counter (contact)
CNTC
TC
0 - 4095
R
Word Device
Device Name
Device Symbol
Address Range
Read
/Write
Address
Gradual
MICRO/I
PLC
Input/Output Internal Relay
WR
CIO
0 - 999, 1200 - 6143
R/W
Link Relay
WLR
LR
0 - 199
R/W
Holding Relay
WHR
HR
0 - 511
R/W
Auxiliary Memory Relay
WAR
AR
0 - 959
R
Timer (current value)
TIMN
TC
0 - 2047
R
Counter (current value)
CNTN
TC
0 - 4095
R
Data Memory
DM
DM
0 - 9999
R/W
Important points to note regarding setting performing Bit Write operations.
With a Bit Write operation, the word data is first read from the PLC, and a logic operation (AND or OR) is performed on
the relevant bit before writing it to the PLC to ensure that the values of other bits in the same channel are preserved. How-
ever, be certain that the PLC does not modify the data in the channel during the time that the MICRO/I is writing the data.
