External device setup manual – IDEC High Performance Series User Manual
Page 491

473
18 FUJI
2
2
2
2
2
2
2
2
2
2
2
2
2
2
2
Con
nection
to a PLC
External Device Setup Manual
18.5.3
MICREX-SX
Word Device
Device Name
Device Symbol
Address Range
Read
/Write
Address
Gradual
MICRO/I
PLC
Input memory
*1
*1. The virtual addresses for I/O memory differs according to the system configuration.
To read and write to the I/O memory area, handle this with indirect access through the standard memory in the MICREX-SX.
-
%IW
-
-
-
Output memory
-
%QW
-
-
-
Standard memory
MW1
%MW1
0 - 2490367
R/W
Dec
Retained memory
MW3
%MW3
0 - 425983
R/W
Dec
System memory
MW10
%MW10
0 - 511
R/W
Dec
