Chapter 2
310
External Device Setup Manual
9.5
Usable Devices
9.5.1
TOYOPUC-PC3J
Bit Device
Device Name
Device Symbol
Address Range
Read
/Write
Address
Gradual
MICRO/I
PLC
Input Relay
X
X
0 - 7FF
R/W
Output Relay
Y
Y
0 - 7FF
R/W
Internal relay
M
M
0 - 7FF
R/W
*1
Keep-relay
K
K
0 - 2FF
R/W
Link relay
L
L
0 - 7FF
R/W
Special relay
V
V
0 - FF
R/W
Edge detection
P
P
0 - 1FF
R/W
Timer contact
T
T
0 - 1FF
R
Counter contact
C
C
0 - 1FF
R
Internal relay
P3M
M
0 - 7FF
R/W
Keep-relay
P3K
K
0 - 2FF
R/W
Link relay
P3L
L
0 - 7FF
R/W
Special relay
P3V
V
0 - FF
R/W
Edge detection
P3P
P
0 - 1FF
R/W
Timer contact
P3T
T
0 - 1FF
R
Counter contact
P3C
C
0 - 1FF
R
Internal relay
P2M
M
0 - 7FF
R/W
Keep-relay
P2K
K
0 - 2FF
R/W
Link relay
P2L
L
0 - 7FF
R/W
Special relay
P2V
V
0 - FF
R/W
Edge detection
P2P
P
0 - 1FF
R/W
Timer contact
P2T
T
0 - 1FF
R
Counter contact
P2C
C
0 - 1FF
R
Internal relay
P1M
M
0 - 7FF
R/W
Keep-relay
P1K
K
0 - 2FF
R/W
Link relay
P1L
L
0 - 7FF
R/W
Special relay
P1V
V
0 - FF
R/W
Edge detection
P1P
P
0 - 1FF
R/W
Timer contact
P1T
T
0 - 1FF
R
Counter contact
P1C
C
0 - 1FF
R
