539

22 Emerson

2

2

2

2

2

2

2

2

2

2

2

2

2

2

2

Con

nection

to a PLC

External Device Setup Manual

22.5 Usable Devices

When the Emerson ROC Protocol host I/F driver is selected, check the usable PLC devices in the Device Address Settings dialog
box.

Click [...] for the option to configure device addresses to display the Device Address Settings dialog box.

Example: To set a PLC device to the Bit Button.

1. Place the Bit Button on the screen and double click to edit it.

The Properties dialog box will be displayed.
