20.5 Usable Devices
Bit Device
Device Name
Device Symbol
Address Range
Read
/Write
Address
Gradual
MICRO/I
PLC
I/O Relay (bit)
P
P
0 - 31F
R/W
HEX
Auxiliary Relay (bit)
M
M
0 - 191F
R/W
HEX
Keep Relay (bit)
K
K
0 - 31F
R/W
HEX
Link Relay (bit)
L
L
0 - 63F
R/W
HEX
Special Relay (bit)
F
F
0 - 63F
R
HEX
Timer (Contact)
TS
T
0 - 255
R/W
DEC
Counter (Contact)
CS
C
0 - 255
R/W
DEC
Word Device
Device Name
Device Symbol
Address Range
Read
/Write
Address
Gradual
MICRO/I
PLC
I/O Relay (word)
WP
P
0 - 31
R/W
DEC
Auxiliary Relay (word)
WM
M
0 - 191
R/W
DEC
Keep Relay (word)
WK
K
0 - 31
R/W
DEC
Link Relay (word)
WL
L
0 - 63
R/W
DEC
Special Relay (word)
WF
F
0 - 63
R
DEC
Timer (Current Value)
T
T
0 - 255
R/W
DEC
Counter (Current Value)
C
C
0 - 255
R/W
DEC
Data Register
D
D
0 - 4999
R/W
DEC
