Chapter 6
630
External Device Setup Manual
3
Settings of the 1: N Communication
3.1
Initial Setting
When creating a project or converting the Host I/F, set the “Connection Type” to “1: N Communication”.
“Connection Type” can only be changed with the Communication Driver supporting 1: N Communication.
3.2
External Device Settings
3.2.1
Common setting
When 1: N Communication is specified, configure the device setting according to the format below. This applies to the external
device settings only.
{Station No.} {Delimiter} {Device Symbol} {Space} {Device Address}
Note: {Delimiter} is a colon “:”
Example) 1: D 1000
3.2.2
Ethernet communication driver
In case of Ethernet communication driver, attach IP address and Port number for PLC to Station number.
Configure communicated PLC information on Host I/F Network in Project Settings.
