Chapter 2- Drive System: CVT and Transfer Case
61
1
Apply a small amount of permanent thread locking
compound such as Loctite® 262 (red) to the screws
that hold the caliper bracket to the case.
2
Apply a small amount of thread sealant. PTFE-
based tape or liquid products are suitable.
3
Apply a small amount of “Service Removable” or
“Medium Strength” threadlocking compound such as
Loctite® 242 (blue) to the screws that hold the caliper
bracket to the case.
Item ft-lbs N-m
Reverse idler bolt
1 32-40 43-54
Neutral safety
switches
2
32-36 43-49
Detent plate screw 16-21 23
Case screws 16-21 23
Adaptor housing
screws
3
16-21 23
Drain and level plugs 18-23 25-32
Fill plug and vent snug snug
Shift arm bracket
3 16-21 23
Shift arm pivot bolt 9 13
Shift arm / shift pin
shoulder screws
3
9 13
Brake caliper bracket
screws
1
16-21 23
Brake caliper bolts
1 16-21 23
