Function library
Selection of control mode, optimisation of operating behaviour
7−6
L
EDB82MV752 EN 5.2
Typical values for C0015
400 V E82xVxxxK4 controller 230 V E82xVxxxK2 controller
motor C0015 motor C0015
Voltage Frequency Connection Voltage Frequency Connection
230/400 V 50 Hz * 50 Hz 230/400 V 50 Hz F 50 Hz
220/380 V 50 Hz
*
52.6 Hz 220/380 V 50 Hz F 52.3 Hz
280/480 V 60 Hz * 50 Hz
400/690 V
400 V 50 Hz
50 Hz
F
50 Hz
230/400 V
280/480 V
400 V 50 Hz
60 Hz
87 Hz F 87 Hz
220/380 V 50 Hz
F
90.9 Hz
)
Note!
l 4−pole asynchronous motors which are designed for a rated frequency of 50 Hz
in star connection, can be operated in delta connection if the constant
excitement does not exceed 87 Hz.
– The motor current and the motor power increase by the factor
Ö3 = 1.73.
– The field−weakening range starts above 87 Hz.
l Advantages:
– Higher speed−setting range
– 73 % higher power output with standard motors.
l In principle, this method can also be used for motors with other pole numbers.
– Observe the mechanical limit speed when using 2−pole asynchronous motors.
