Parameter setting
With communication module LECOM−A (RS232)
6−14
L
EDB82MV752 EN 5.2
Code Important Parameter
No. Settings/options LECOM
format Designation
C0249 * LECOM code
bank VD Code bank Addressable codes
·
For compatibility with LECOM−A/B drivers V1.0 (maximum possible
code number 255).
·
With the code bank, an offset of 250 is added to the code number.
·
Together with LECOM.A/B drivers from V2.0 on, C0249 is
ineffective.
·
With every switch−on, C0249 is set to 0.
0 0000 ... 0255
1 0250 ... 0505
2 0500 ... 0755
3 0750 ... 1005
4 1000 ... 1255
5 1250 ... 1505
6 1500 ... 1755
7 1750 ... 2005
8 2000 ... 2255
9 2250 ... 2505
10 2500 ... 2755
11 2750 ... 3005
12 3000 ... 3255
13 3250 ... 3505
14 3500 ... 3755
15 3750 ... 4005
C1810 * SW
identification VS Structure: 33S2102I_xy000 Software identification (x = main version, y = subversion)
C1811 * SW creation VS Date of software creation
C1920 Starting status VD 0 QSP (quick stop) After mains switching the drive is in QSP" status.
1 CINH (controller inhibit) After mains switching the drive is in CINH" status.
Writing of C0040 =1
Þenable
C1921 Reduced
response time
VD 0 Not active C1921 = 1:
·
A write telegram (send) is only checked for transmission errors:
– A faulty telegram is acknowledged positively (ACK), otherwise
negatively (NAK).
– Only after this the value is transmitted to the controller.
·
It is not guaranteed that the controller has adopted the value
correctly.
·
The communication module can be readdressed after 50 ms.
1 Active
C1922 Communication
monitoring
response
VD 0 Not active
·
Use C1922 and C1923 to monitor the communication connection to
the host.
·
If the host does not send a telegram to the communication module
during the monitoring time set under C1923, the action set under
C1922 will be executed.
1 CINH (controller inhibit)
2 QSP (quick stop)
C1923 Monitoring time 50 {ms} 65535
