Technical data
Rated data at 400/500 V mains voltage
3−9
L
EDB82MV752 EN 5.2
3.3.2
Operation with increased rated power
Under the application conditions described here the controller can be operated in continuous
operation with a motor of higher performance. The overload capacity is reduced to 120 %.
·
Typical applications:
– Pumps with quadratic load characteristic
– Fan
·
Operation is only permissible
– in the mains voltage ranges mentioned
– at a switching frequency of 2 or 4 kHz
– with the prescribed fuses and cable cross−sections
Typical motor power
Three−phase asynchronous motor
(4−pole)
P
N
[kW]
0.75
1.1
2.2
3.0
P
N
[hp]
1.0
1.5
3.0
4.0
8200 motec
Type
E82MV551_4B
E82MV751_4B
E82MV152_4B
E82MV222_4B
Mains voltage
U
mains
[V]
3/PE AC 320 V − 0 % ... 440 V + 0 % ;
45 Hz − 0 % ... 65Hz + 0 %
Data for operation on 3/PE AC
400 V
400 V
400 V
400 V
Rated mains current
I
mains
[A]
2.2
2.8
4.6
6.6
Rated output current at
switching frequency
2 kHz
I
N24
[A]
2.1
2.9
4.6
6.7
4 kHz
Max. permissible output
current for 60 s at
switching frequency
1)
2 kHz
I
max24
[A]
2.7
3.6
5.8
8.4
4 kHz
Output voltage
U
M
[V]
3~ 0 ... U
mains
/ 0 ... 650 Hz
Power loss (operation with I
N8
)
P
v
[W]
35
45
70
95
Dimensions
L x W x H [mm]
202 x 156 x 151
230 x 176 x 167
Weight
m [kg]
2.8
2.8
4.1
4.1
Typical motor power
Three−phase asynchronous motor
(4−pole)
P
N
[kW]
4
5.5
7.5
P
N
[hp]
5.4
7.5
10.2
8200 motec
Type
E82MV302_4B
E82MV402_4B
E82MV552_4B
Mains voltage
U
mains
[V]
3/PE AC 320 V − 0 % ... 440 V + 0 % ;
45 Hz − 0 % ... 65Hz + 0 %
Data for operation on 3/PE AC
400 V
400 V
400 V
Rated mains current
I
mains
[A]
11.4
14.8
20.2
Rated output current at
switching frequency
2 kHz
I
N24
[A]
8.8
11.4
15.6
4 kHz
Max. permissible output
current for 60 s at
switching frequency
1)
2 kHz
I
max24
[A]
11.0
14.2
19.5
4 kHz
Output voltage
U
M
[V]
3~ 0 ... U
mains
/ 0 ... 650 Hz
Power loss (operation with I
N8
)
P
v
[W]
140
180
230
Dimensions
L x W x H [mm]
325 x 211 x 163 (223**)
Weight
m [kg]
9.7
9.7
9.7
Bold print = data for operation at a switching frequency of 8 kHz (Lenze setting)
1)
Currents for periodic load change with 1 min overcurrent time with I
max
and 2 min base load time with 75 % I
Nx
**
for wall mounting or with a supplementary module (E82ZMV)
