Function library
Parameter set management
7−94
L
EDB82MV752 EN 5.2
7.15.2 Parameter set changeover
Description
During operation you can change between the four parameter sets of the controller via digital
signals. Thus 9 additional JOG values or additional acceleration and deceleration times are
available.
The parameter set changeover via digital signals is not possible if the automatic changeover via
DC−bus voltage is active!
Activation
Link C0410/13 (DCTRL1−PAR2/4) and C0410/14 (DCTRL1−PAR3/4) with a digital signal source.
After being initialised, the controller always operates with parameter set 1. Only when a signal for
parameter set changeover is active, the controller changes the parameter set.
)
Note!
l C0410/13 and C0410/14 must be linked with the same signals in all parameter
sets!
l Start the parameter setting with the highest parameter set. Parameterise the
parameter set 1 at the end. In this way undefined states can be prevented
l If the control mode (C0014) is different for the parameter sets, you should only
switch between the parameter sets when the controller is inhibited (CINH).
Signal source Active parameter set
Level at C0410/13 Level at C0410/14
LOW LOW Parameter set 1 (PAR1)
HIGH LOW Parameter set 2 (PAR2)
LOW HIGH Parameter set 3 (PAR3)
HIGH HIGH Parameter set 4 (PAR4)
)
Note!
Use C0007 to link the changeover between parameter set 1 and parameter set 2
with the digital inputs X3/E2 or X3/E3.
