Page 41: 4 wiring of bus function modules
Installation
Electrical installation − Connections
4−16
L
EDB82MV752 EN 5.2
X3.3/
−6−
Signal type
Function
Level
(Lenze setting, in bold print)
A1
Digital outputs
Ready for operation
0/+20 V at DC internal
0/+24 V at DC external
A2
not prefabricated
7
−
GND, reference potential
−
A4
Frequency
output
DC bus voltage
HIGH:
+18 V...+24 V (HTL)
LOW: 0 V
59
−
DC supply for X3/A1 and X3/A2
+20 V (internal, bridge to X3/20)
+24 V (external)
20
−
Internal DC voltage supply for control of digital inputs and output +20 V
± 10 %
28
Digital inputs
Controller inhibit (CINH)
1 = START
E1
2)
Activation of JOG frequencies
JOG1 = 20 Hz
JOG2 = 30 Hz
JOG3 = 40 Hz
E1
E2
JOG1
1
0
E2
2)
JOG2
0
1
JOG3
1
1
E3
DC−injection brake (DCB)
1 = DCB
E4
Change of direction of rotation
CW/CCW rotation
E4
CW
0
CCW
1
E5
not prefabricated
−
E6
not prefabricated
−
2)
Optional frequency input 0 ... 102.4 kHz, single−tracked or double−tracked, configuration via C0425
4.2.4.4
Wiring of bus function modules
·
System bus (CAN): see CAN Communication Manual
·
For all other bus function modules (e.g. PROFIBUS−DP, INTERBUS, ...) see the accompanying
Mounting Instructions or Communication Manual.
