Toshiba Magnia 3030 User Manual

Page 92

Installing and Removing Hardware
CPU Module

Installing the fan duct

10 Install the server panels.

11 Connect the power cable and turn on the power of the server.

For the EPS-R model, set the DC operate switch to ON and then turn on the
power.

12 Press the key during activation to start the BIOS setup utility and

change the “Processor Retest” set value in a server menu to “Yes”.

13 Save the changed value and restart.

14 Confirm that the replaced CPU module is recognized properly with the dis-

play on the screen.

If it is properly recognized, the same information on CPU is displayed in
two lines.

(The example below shows the case of 700 MHz, 2-CPU configuration.).

Phoenix BIOS 4.0 Release6.0

L440GX0.86B.XXXX.XXXXXXXXXXXXX

L440GX+ Production Release XX.X

BIOS Build XXX

Intel(R) Pentium (R) III Processor 700eMHz

XXXXXXXX Extended Memory ECC Initialized
