Getting Started
Front view (with the front doors opened)
15
*1About the procedures for enabling and disabling the Auto SD/Remote Indication function
*2About flashing of the Fault lamp
See “Lamp indication in case of the occurrence of an EPS-R cage failure or cooling fan unit
failure” described below.
Indicator
(lamp)
Status
Meaning
Power
Off
Out of operation (AC power not supplied)
Lit amber
Out of operation (AC power supplied) or power on (for EPS-R
models only)
Flashing
green
In power saving mode (sleep mode)
Lit green
In operation
Disk
Off
Out of operation
Flashing
amber
Disk array being rebuilt
(Valid only when the RAID controller is in use.)
Lit amber
Disk failure occurred
(Valid only when the RAID controller is in use.)
Flashing
green
Disk drive in operation
(For models without a RAID controller, this indicator also
flashes when another SCSI device connected to the on-board
SCSI controller is running.)
Auto SD/
Remote
Off
One of the following statuses:
- Out of operation
- The Auto SD/Remote Indication function is disabled and a
program is running on an operating system (Windows 2000,
NetWare etc.) other than Windows NT. *1
Lit amber
The Auto SD/Remote Indication function is disabled.
- The Auto SD/Remote indication program is not installed on
Windows NT or is not running normally.
- Windows NT is in process of starting up.
- The Auto SD/Remote Indication function is enabled and a pro-
gram is running on an operating system other than Windows
NT. *1
Lit green
The Auto SD/Remote Indication function is enabled.
In this status, turning off the power switch enables the Auto
Shutdown function.
Fault
Off
Out of operation, or both the power supply and the cooling fan
unit are operating normally.
Flashing
green and
amber
One module of the redundant cooling fan unit or power supply
unit has failed. (The system can be operated continuously.) *2
Flashing
amber
One module of the non-redundant cooling fan unit or power
supply unit has failed, or two or more modules of the redundant
cooling fan unit or power supply unit have failed. (The server
must be shut down immediately.)
Off
